The Brave 3-in. commercial-grade trash pump is ideal for moving large amounts of water that may contain solids such as leaves, pebbles, or twigs. This heavy-duty unit can move entire ponds making it ideal for farmers and contractors. The commercial-grade pump moves liquids faster so you can get the job done quickly. This unit can filter particles up to 1-1/4 in. in diameter. Hose kits are available.
Features
- Cast iron impeller
- One tool serviceability tool included
- Silicon carbide mechanical seal with graphite-impregnated seat and Viton elastomers
- Heavy-duty steel roll frame and strainer included
- Built-in EPDM/EPR check value
- Removable/replaceable cast iron suction/discharge parts
- Discharge port rotates in 90º increments
- Vibration dampening feet
- Max temperature of 180ºF
- Self-priming to 26 ft.
- Max solids handling up to 1-1/4 in.
- Optional wheel kit available
Specifications
| Equipment Type | Pump (Trash) |
| Discharge Capacity | 290 Gal/min |
| Discharge Port Diameter | 3 In. Npt |
| Displacement | 196cc |
| Dry Weight | 100 Lbs |
| Engine | Gx200 |
| Engine Brand | Honda |
| Impeller | Cast Iron |
| Mechanical Seal (Pump Case/Impeller) | Silicon Carbide Mechanical Seal With Graphite Impregnated Seat And Viton® Elastomers |
| Pressure | 48 Psi Max |
| Pump Type | Trash |
| SKU | BRP520TP3 |
| Solids Handling | Up To 1-1/4 In. Diameter |
| Suction Port Diameter | 3 In. Npt |
| Total Head Lift | 110 Ft. |
